Mercury® Diesel 3.0L (150-270hp)
Mercury® Diesel 3.0L (150-270hp)

Mercury® Diesel 3.0L (150-270hp)

VGT design
Whether it’s getting started, cruising on plane or running wide open, the variable geometry turbocharger (VGT) design automatically optimises power and torque to meet demand.

Closed cooling system
A thermostatically controlled closed-loop freshwater cooling system protects the engine and turbocharger in both fresh and saltwater.

Advanced ECU
Our advanced engine control unit (ECU) intelligently manages engine systems to reduce emissions and optimise overall performance.

HPCR fuel injection
The high-pressure common rail (HPCR) fuel injection system fine-tunes the air-to-fuel ratio to enhance acceleration, top speed and efficiency.

Ample charging output
A powerful alternator delivers 110 amps of charging power at wide-open throttle – perfect for keeping onboard electronics running long into the fun.

SeaCore
Take on the toughest marine conditions with the available SeaCore® system. It is an entire package of durable, corrosion-fighting technology that offers an extraordinary level of protection.

Specifications

Mercury Diesel: 270 hp Sterndrive

Alternator amp / watt - 12 V 110 A

Displacement (L) - 3.0L

Engine type - V6

HP / kW - 270 / 201

Maximum RPM (WOT) - 4200

Compatible drives - Bravo One X / Bravo Three X / Bravo Two X

Oil maintenance interval - 200 hours or annually

Oil sump volume - 8.5 L

Peak torque - 594 Nm @ 2200 rpm

Recommended fuel - Diesel

Recommended oil - 5W30 ACEA C3 synthetic oil

Mercury Diesel: 230 hp Sterndrive

Alternator amp / watt - 12 V 110 A

Displacement (L) - 3.0L

Engine type - V6

HP / kW - 230 / 171

Maximum RPM (WOT) - 4200

Compatible drives - Bravo One X / Bravo Three X / Bravo Two X

Oil maintenance interval - 200 hours or annually

Oil sump volume - 8.5 L

Peak torque - 503 Nm @ 2200 rpm

Recommended fuel - Diesel

Recommended oil - 5W30 ACEA C3 synthetic oil

Mercury Diesel: 150 hp Sterndrive

Alternator amp / watt - 12 V 110 A

Displacement (L) - 3.0L

Engine type - V6

HP / kW - 150 / 110kW

Maximum RPM (WOT) - 3000

Weight (engine only) Ibs / kg - 348 / 767

Compatible drives - Bravo One X / Bravo Three X / Bravo Two X

Oil maintenance interval - 200 hours or annually

Oil sump volume - 8.5 L

Peak torque - 493 Nm @ 2000 rpm

Recommended fuel - Diesel

Recommended oil - 5W30 ACEA C3 synthetic oil
